API Thermo-Hydrometer ASTM, 49 to 61 degree API Range, 0 to 150 degree F, 380mm Length

API Thermo-Hydrometer ASTM, 49 to 61 degree API Range, 0 to 150 degree F, 380mm Length

API GRAVITY MEASUREMENT: A DEFINITION

The American Petroleum Institute gravity, or API Thermo-hydrometer, is a measure of how heavy or light a petroleum liquid is compared to water: if its API gravity is greater than 10, it is lighter and floats on water; if less than 10, it is heavier and sinks.

API gravity is an inverse measure of a petroleum liquid's density relative to that of water.

It is used to compare densities of petroleum liquids. For example, if one petroleum liquid is less dense than another, it has a greater API gravity.

Although API gravity is mathematically a dimensionless quantity, it is referred to as being in 'degrees'. API gravity is graduated in degrees on a hydrometer instrument. API gravity values of most petroleum liquids fall between 10 and 70 degrees.

Thermo-hydrometers conform to ASTM specifications. Unit includes thermometer in the body. Temperature of standardization is 60 degree F. 0.1 degree division. 380mm Length. Thermometer Range 0 to 150 degree F. 49 to 61 API Range.

---

Product Specifications

Length	380 millimeters
Number of Items	1
Part Number	56H
Size	49/61 API, 0.1 degree Division, 380mm Length
Upper Temperature Rating	150 degrees_fahrenheit

API Chapter 9.3 of the MPMS ASTM D and E100. These instruments combine API gravity scale with a thermometer in the body and are the standard and preferred size normally used for determining the gravity of crude oil and other liquid petroleum products.

Length:15 inch (374 to 387 mm)
Diameter:¾ to 1 inch (18 to 25 mm)
Thermometer Range: 0 to 150 F

SELECT MODEL

51HL API -1/11 0.1 DIV, 0/150F, 2.0 DIV
52HL API 9/21 0.1 DIV, 0/150F, 2.0 DIV
53HL API 19/31 0.1 DIV, 0/150F, 2.0 DIV
54HL API 29/41 0.1 DIV, 0/150F, 2.0 DIV
55HL API 39/51 0.1 DIV, 0/150F, 2.0 DIV
56HL API 49/61 0.1 DIV, 0/150F, 2.0 DIV
57HL API 59/71 0.1 DIV, 0/150F, 2.0 DIV
58HL API 69/81 0.1 DIV, 0/150F, 2.0 DIV
59HL API 79/91 0.1 DIV, 0/150F, 2.0 DIV
60HL API 89/101 0.1 DIV, 0/150F, 2.0 DIV
